Camview 4 Channel WiFi NVR Security Camera System Review

Camview 4 Channel WiFi NVR Security Camera System Review

Buy it at Amazon: Camview 4 Channel WiFi NVR Security Camera System [Affiliate Link]

Takeaway: Fairly easy and quick setup, clear HD video (no audio), handy mobile app, instructions could be better.

The NVR unit comes with a quick installation guide, a pack of 4 hard drive screws (for 3.5" HDD), a remote control, an A/C adapter for the main unit, a USB mouse, a 3 ft CAT5 Ethernet cable, and 4 individually packed wireless cameras with A/C adapters. The only thing you'll need to provide is a SATA hard drive up to 6GB for recording the video footage. I used a Western Digital 500 GB 2.5" HDD, but because it's smaller I had to use different screws than the ones that were included to mount it to the NVR housing. On the back of the NVR are two 7 inch wireless antennae and along the bottom is the VGA outout, HDMI output, WAN port, USB port, and power port. In front, you have some on-board playback controls and menu selection keys as well as various indicator LEDs. This model does not have a front USB port so only one USB device can be used at a time e.g. mouse, USB thumb drive.

Each camera comes with a 7" antenna, waterproof housing for the Ethernet connection, a pack of wall mounting hardware, and A/C adapter. On the front under the lens is a light sensor so that the camera can detect when there is low light to activate infrared night vision. The camera can pivot 90 degrees and to set the angle at the joint use the small Allen wrench in the hardware package to loosen the adjustment screw. Rotation can only be set at the point of installation when you drill the holes to mount the camera. The camera body is made of metal and very durable for weather-resistance. Setup is basically plug and play. The power cable connects to the barrel port on the extending cable. The other connector is for an optional LAN connection but does not need to be used (no cap is included to cover the unused port). Once plugged in and powered on, the camera will be transmitting a live feed, so all you need to do is turn on the NVR unit.

When connecting the NVR to my TV via HDMI for monitoring the output resolution is HD at 1080p; each camera when viewed indivually also supports 1920x1080 resolution. Once booted up, the NVR will search for the 4 cameras and connect to them automatically which takes a few minutes. You do have to format the hard drive before it can record to it, and I found it easiest to navigate the menus using the USB mouse since the cursor is tricky to maneuver with the arrow keys on the remote. The remote control which requires 2 AAA batteries which are not included. In the settings you can change the network settings, schedules, and triggers for the camera for recording. You can also monitor the cameras using your smart phone by downloading the CamView Cloud app from the Google Play or Apple store. The app requires you to sign up for an account to use it. The instructions don't tell you how to add the NVR to the list of device in the app, but in the app, tap the '+' icon in the upper right and select "Add device by ID." Then use the "Cloud ID" found in the bottom right corner of the monitor screen (hook up NVR to TV) and provide the default login of 'Admin' and a blank password.

After adding the NVR to the list of devices, you'll be able to see the four camera feeds live on your phone. Tapping one screen will zoom in on it. The infrared lights allows you to see everything in total darkness as if it were daytime, but in black and white. On the phone, the video image appears slightly washed out, but the color representation and resolution are actually decent on a TV/computer monitor. In the app, you can playback and save previously recorded video and capture still images. You can also download videos directly to a thumb drive on the NVR with a USB thumb drive, though you won't be able to use the mouse the navigate the menus while the thumb drive is plugged in.

Overall, the security camera system is pretty quick the setup, and it's easy to use. The instructions could be clearer on how to add the NVR to the mobile app and it doesn't tell you the default login for the menu is 'admin' with a blank password. However, once you're up and running it's dead simple to check on the cameras and review or save recorded video.

Buy it at Amazon: Camview 4 Channel WiFi NVR Security Camera System [Affiliate Link]

Comments

  1. I am having trouble showing video on my phone. What is the device name or ID?
    Keeps showing offline. I can hook a monitor to the unit and it shows up just fine.

    ReplyDelete
    Replies
    1. Ok, if you can view the cameras on the monitor, look in the bottom right hand corner of the monitor. You should see the "ID" there in the corner. In the app, tap the '+' icon in the upper right and select "Add device by ID." Then use the "Cloud ID" found in the bottom right corner of the monitor in this field and provide the default login of 'Admin' and a blank password.

      Delete
